Internal Combustion Counterbalanced Forklift Truck

Characteristics

1.01

Manufacturer

HELI

1.02

Model

CPD30

1.03

Config No.

GC2

1.04

Load capacity

kg

3000

1.05

Load center

mm

500

1.06

Power type

Battery

1.07

Seated-type

Seated

1.08

Wheelbase

mm

1685

Tire

2.01

Tire(front/rear)

Pneumatic tire

2.02

Tire N. X=Driving wheel(front/rear)

2/2

2.03

Tread(front)

mm

1000

2.04

Tread(rear)

mm

950

2.05

Tire Model(front)

28*9-15-12

2.06

Tire Model(rear)

18*7-8-14

Dimensions

3.01

Front overhang

mm

485

3.02

Mast tilt angle front/rear

°

6/10

3.03

Mast height

mm

2075

3.04

Full free lifting height

mm

145

3.05

Max lifting height

mm

3000

3.06

Max height under working condition

mm

4230

3.07

Overhead height

mm

2215

3.08

Fork size T*W*L

mm

45*125*1070

3.09

Lateral fork adjustment(outside of forks)

mm

1060/250

3.10

Fork arm carrier,Din standard

3A

3.11

Overall length(with fork/without fork)

mm

2490

3.12

Overall width

mm

1241

3.13

Turning radius

mm

2210

3.14

Clearance between mast and ground

mm

135

3.15

Base center and ground(loaded)

mm

145
